Pluggable Terminal Blocks

: 338 Products Found

Filter Layout: LEFT

TOP

0 Filter(s) Selected

Products Found Please click the 'Apply Filters' button to update results

Keep applying filters or Show Results Show Results

Apply Filters

Filters

Clear All Filters

Min/Max Product Range

Reset

Contract pricing display is unavailable at the moment. Prices shown are standard retail prices, orders placed will have contract pricing applied when processed.

Open Filters

Manufacturer Part No	Order Code	Description / Manufacturer	Price For	Price Ex. VAT (Inc. VAT)	Quantity	Pitch Spacing	For Use With	No. of Positions	Accessory Type	Wire Size AWG Min	Wire Size (AWG)	Wire Size AWG Max	Conductor Area CSA	Wire Connection Method	Rated Current	Rated Voltage	Product Range
						Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending	Sort Acending Sort Decending
HY434/12 NYSP	CN21670 Data Sheet + RoHS	12-Pole Plug & Socket Terminal Block, 450V AC, 45A, Polyamide PA6.6 HYLEC The HY434/12 NYSP from Hylec is a 12-Pole plug and socket terminal block constructed from natural Polyamide PA6.6. The HY434/12 NYSP has a 12mm pitch and a rating of 45A at 450VAC. • UL94 rating: UL94V2 • Minimum conductor size: 10mm² • Maximum voltage: 45... You previously purchased this product. View in Order History	Each	1+ €6.435 (€7.92) 10+ €6.1074 (€7.51) 25+ €5.9085 (€7.27)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	12mm	-	12Ways	-	-	-	-	10mm²	Screw	45A	450V	HY434
FK-MC 0,5/2-ST-2,5	CN21725 Data Sheet + RoHS	2.5mm Pluggable Terminal Block, 2-Pole, 26AWG - 20AWG, 160V, 4A PHOENIX CONTACT The FK-MC 0,5/2-ST-2,5 is a 2-position green PCB Terminal Block with tin-plated contacts, a polyamide insulator and the push-in spring connection. This 1881325 terminal block has possible combinations with MC 0,5 and MCD 0,5 base strips with 2.5mm pitch. I... You previously purchased this product. View in Order History	Each	1+ €1.8369 (€2.26) 10+ €1.7316 (€2.13) 50+ €1.6497 (€2.03)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	2.5mm	-	2Ways	-	26AWG	26AWG to 20AWG	20AWG	0.5mm²	Push In	4A	160V	FK-MC
HY115/16 NYSP	CN21672 Data Sheet + RoHS	16 Pole Plug & Socket Terminal Block, 450V AC, 35A, Polyamide PA6.6, White HYLEC The HY115/16 NYSP from Hylec is a 16-Pole plug and socket terminal block constructed from natural Polyamide PA6.6. The HY115/16 NYSP has a 11.5mm pitch and a rating of 35A at 450V AC. • Minimum conductor size: 6mm² • Maximum voltage: 450V AC • Maximum curr... You previously purchased this product. View in Order History	Each	1+ €10.4481 (€12.85) 10+ €10.1088 (€12.43) 25+ €9.7578 (€12.00)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	11.5mm	-	16Ways	-	-	-	-	6mm²	Screw	35A	450V	HY115
MC000058	CN21992 Data Sheet + RoHS	3.5mm Pluggable Terminal Block, Plug, 4 Way, 26AWG to 16AWG, 10A MULTICOMP PRO The MC000058 is a 4-way 3.5mm pluggable PCB Terminal Block with tin plated phosphor bronze terminal, green polyamide 66 insulating body and straight block orientation. It accepts 16AWG wire gauge. • <gt/>2000MΩ Insulation resistance • -40 to +105°C Operati... You previously purchased this product. View in Order History	Each	1+ €1.0179 (€1.25) 10+ €0.8892 (€1.09) 50+ €0.7956 (€0.98)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.5mm	-	4Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-
MC000184	CN22025 Data Sheet + RoHS	5.08mm Pluggable Terminal Block, Plug - R/A, 2 Way, 24AWG to 14AWG, 16A MULTICOMP PRO The MC000184 is a 2-way 16A right-angle Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a nickel-plated steel screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • ... You previously purchased this product. View in Order History	Each	1+ €0.468 (€0.58) 10+ €0.4095 (€0.50) 25+ €0.3627 (€0.45)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	5.08mm	-	2Ways	-	24AWG	24AWG to 14AWG	14AWG	-	Screw	16A	300V	-

MC000056	CN21990 Data Sheet + RoHS	3.5mm Pluggable Terminal Block, Plug, 2 Way, 26AWG to 16AWG, 10A MULTICOMP PRO The MC000056 is a 2-way 3.5mm pluggable PCB Terminal Block with tin plated phosphor bronze terminal, green polyamide 66 insulating body and straight block orientation. It accepts 16AWG wire gauge. • <gt/>2000MΩ Insulation resistance • -40 to +105°C Operati... You previously purchased this product. View in Order History	Each	1+ €0.4797 (€0.59) 10+ €0.4329 (€0.53) 50+ €0.3861 (€0.47)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.5mm	-	2Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-

MC000059	CN21993 Data Sheet + RoHS	3.5mm Pluggable Terminal Block, Plug, 5 Way, 26AWG to 16AWG, 10A MULTICOMP PRO The MC000059 is a 5-way 3.5mm pluggable PCB Terminal Block with tin plated phosphor bronze terminal, green polyamide 66 insulating body and straight block orientation. It accepts 16AWG wire gauge. • <gt/>2000MΩ Insulation resistance • -40 to +105°C Operati... You previously purchased this product. View in Order History	Each	1+ €1.1466 (€1.41) 10+ €1.0062 (€1.24) 50+ €0.8541 (€1.05)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.5mm	-	5Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-

MC000101	CN22009 Data Sheet + RoHS	3.81mm Pluggable Terminal Block, Plug, 8 Way, 26AWG to 16AWG, 10 A MULTICOMP PRO The MC000101 is a 8-way 10A straight Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a nickel-plated steel screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • <gt... You previously purchased this product. View in Order History	Each	1+ €1.7433 (€2.14) 10+ €1.5912 (€1.96) 25+ €1.4625 (€1.80)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.81mm	-	8Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-

HY433/12 FVSP	CN21668 Data Sheet + RoHS	12-Pole Plug & Socket Terminal Block, 450V AC, 28A, Polyamide PA6.6 HYLEC The HY433/12 NYSP from Hylec is a 12-Pole plug and socket terminal block constructed from natural Polyamide PA6.6. The HY433/12 NYSP has an 10mm pitch and a rating of 28A at 450V AC. • UL94 rating: UL94V2 • Minimum conductor size: 4mm² • Maximum voltage: 4... You previously purchased this product. View in Order History	Each	1+ €5.382 (€6.62) 10+ €5.1012 (€6.27) 25+ €4.9374 (€6.07)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	10mm	-	12Ways	-	-	-	-	4mm²	Screw	28A	450V	HY433/12

MC000060	CN21994 Data Sheet + RoHS	3.5mm Pluggable Terminal Block, Plug, 6 Way, 26AWG to 16AWG, 10A MULTICOMP PRO The MC000060 is a 6-way 3.5mm pluggable PCB Terminal Block with tin plated phosphor bronze terminal, green polyamide 66 insulating body and straight block orientation. It accepts 16AWG wire gauge. • <gt/>2000MΩ Insulation resistance • -40 to +105°C Operati... You previously purchased this product. View in Order History	Each	1+ €1.2987 (€1.60) 10+ €1.0647 (€1.31) 50+ €0.9711 (€1.19)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.5mm	-	6Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-

HY434/12 PLPSP	CN21669 Data Sheet + RoHS	12-Pole Plug & Socket Terminal Block, 450V AC, 45A, Polypropylene HYLEC The HY434/12 PLPSP from Hylec is a 12-Pole plug and socket terminal block constructed from natural Polypropylene. The HY434/12 NYSP has an 10mm pitch and a rating of 45A at 450VAC. • UL94 rating: UL94V2 • Minimum conductor size: 10mm² • Maximum voltage: 45... You previously purchased this product. View in Order History	Each	1+ €6.1308 (€7.54) 10+ €5.8149 (€7.15) 25+ €5.6277 (€6.92)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	12mm	-	12Ways	-	-	-	-	10mm²	Screw	45A	450V	HY434

MC000100	CN22008 Data Sheet + RoHS	3.81mm Pluggable Terminal Block, Plug, 6 Way, 26AWG to 16AWG, 10 A MULTICOMP PRO The MC000100 is a 6-way 3.81mm pluggable PCB Terminal Block with tin plated phosphor bronze terminal, green polyamide 66 insulating body and straight block orientation. It accepts 16AWG wire gauge. • <gt/>2000MΩ Insulation resistance • -40 to +105°C Operat... You previously purchased this product. View in Order History	Each	1+ €1.1349 (€1.40) 10+ €1.0413 (€1.28) 25+ €0.9477 (€1.17)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.81mm	-	6Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-

MC000138	CN22014 Data Sheet + RoHS	5mm Pluggable Terminal Block, Plug, 4 Way, 26AWG to 12AWG, 16A MULTICOMP PRO The MC000138 is a 4-way 16A straight Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a zinc+Cr?³ screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • <gt/>2000MΩ a... You previously purchased this product. View in Order History	Each	1+ €0.7254 (€0.89) 10+ €0.702 (€0.86) 25+ €0.6435 (€0.79)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	5mm	-	4Ways	-	24AWG	24AWG to 12AWG	12AWG	-	Screw	16A	300V	-

MC000068	CN22000 Data Sheet + RoHS	3.5mm Pluggable Terminal Block, Plug - R/A, 6 Way, 8A MULTICOMP PRO The MC000068 is a 6-way 8A right-angle Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a nickel-plated steel screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • <... You previously purchased this product. View in Order History	Each	1+ €1.287 (€1.58) 10+ €1.17 (€1.44) 50+ €1.0764 (€1.32)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.5mm	-	6Ways	-	-	-	-	-	Screw	8A	300V	-

MC000187	CN22028 Data Sheet + RoHS	5.08mm Pluggable Terminal Block, Plug - R/A, 5 Way, 24AWG to 14AWG, 16A MULTICOMP PRO The MC000187 is a 5-way 16A right-angle Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a nickel-plated steel screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • ... You previously purchased this product. View in Order History	Each	1+ €1.1232 (€1.38) 10+ €0.9711 (€1.19) 25+ €0.8541 (€1.05)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	5.08mm	-	5Ways	-	24AWG	24AWG to 14AWG	14AWG	-	Screw	16A	300V	-

MC000141	CN22015 Data Sheet + RoHS	5mm Pluggable Terminal Block, Plug, 8 Way, 26AWG to 12AWG, 16A MULTICOMP PRO The MC000141 is a 8-way 16A straight Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a zinc+Cr?³ screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • <gt/>2000MΩ a... You previously purchased this product. View in Order History	Each	1+ €1.3455 (€1.65) 10+ €1.2636 (€1.55) 25+ €1.17 (€1.44)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	5mm	-	8Ways	-	24AWG	24AWG to 12AWG	12AWG	-	Screw	16A	300V	-

MP007140	CN22900 + RoHS	3 Pole Terminal Block / Splicing Connector with Lever Lock, 4mm, 450V AC, 32A MULTICOMP PRO This Multicomp Pro splicing connector with lever lock allows for solid, stranded and fine stranded cables to be connected together without the need for any tools. • Solid & Stranded Conductors: 4mm² • Voltage: 450V AC • Current: 32A You previously purchased this product. View in Order History	Each	1+ €0.234 (€0.29) 50+ €0.2106 (€0.26) 100+ €0.1872 (€0.23)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	-	-	3Ways	-	-	-	-	4mm²	Push In Lock	32A	450V	-

MC000102	CN22010 Data Sheet + RoHS	3.81mm Pluggable Terminal Block, Plug, 10 Way, 26AWG to 16AWG, 10 A MULTICOMP PRO The MC000102 is a 10-way 10A straight Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a nickel-plated steel screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • <g... You previously purchased this product. View in Order History	Each	1+ €2.0007 (€2.46) 10+ €1.8252 (€2.24) 25+ €1.6614 (€2.04)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.81mm	-	10Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-

FK-MC 0,5/10-ST-2,5	CN21731 Data Sheet + RoHS	2.5mm Pluggable Terminal Block, 10-Pole, 26AWG - 20AWG, 160V, 4A PHOENIX CONTACT The FK-MC series Printed-Circuit Board Connector with operation and conductor connection from one direction enable integration into front of device. The defined contact force ensures that contact remains stable over the long term. • Time saving push-in con... You previously purchased this product. View in Order History	Each	1+ €5.6628 (€6.97) 10+ €5.3703 (€6.61) 50+ €5.1129 (€6.29)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	2.5mm	-	10Ways	-	26AWG	26AWG to 20AWG	20AWG	0.5mm²	Push In	4A	160V	FK-MC

MC000176	CN22018 Data Sheet + RoHS	5.08mm Pluggable Terminal Block, Plug, 2 Way, 26AWG to 12AWG, 16A MULTICOMP PRO The MC000176 is a 2-way 5.08mm pluggable PCB Terminal Block with tin plated phosphor bronze contacts, green polyamide 66 insulating body and straight block orientation. It accepts 12AWG wire gauge. • <gt/>2000MΩ Insulation resistance • -40 to +105°C Operat... You previously purchased this product. View in Order History	Each	1+ €0.4446 (€0.55) 10+ €0.3861 (€0.47) 25+ €0.351 (€0.43)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	5.08mm	-	2Ways	-	24AWG	24AWG to 12AWG	12AWG	-	Screw	16A	300V	-

MC000216	CN22030 Data Sheet + RoHS	7.62mm Pluggable Terminal Block, Plug, 2 Way, 24AWG to 14AWG, 15A MULTICOMP PRO The MC000216 is a 2-way 15A straight Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a zinc+Cr?³ screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • <gt/>2000MΩ a... You previously purchased this product. View in Order History	Each	1+ €0.4095 (€0.50) 10+ €0.3627 (€0.45) 25+ €0.3276 (€0.40)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	7.62mm	-	2Ways	-	24AWG	24AWG to 14AWG	14AWG	-	Screw	15A	300V	-

MC000103	CN22011 Data Sheet + RoHS	3.81mm Pluggable Terminal Block, Plug, 12 Way, 26AWG to 16AWG, 10 A MULTICOMP PRO The MC000103 is a 12-way 10A straight Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a nickel-plated steel screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • <g... You previously purchased this product. View in Order History	Each	1+ €2.5623 (€3.15) 10+ €2.3283 (€2.86) 25+ €2.1177 (€2.60)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.81mm	-	12Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-

MC000217	CN22031 Data Sheet + RoHS	7.62mm Pluggable Terminal Block, Plug, 3 Way, 24AWG to 14AWG, 15A MULTICOMP PRO The MC000217 is a 3-way 15A straight Pluggable Terminal Block with green polyamide 66 insulating body, tin-plated phosphor bronze contacts and a zinc+Cr?³ screw. It has screw wire connection and 2000VAC minimum insulation withstand voltage. • <gt/>2000MΩ a... You previously purchased this product. View in Order History	Each	1+ €0.6201 (€0.76) 10+ €0.5382 (€0.66) 50+ €0.468 (€0.58)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	7.62mm	-	3Ways	-	24AWG	24AWG to 14AWG	14AWG	-	Screw	15A	300V	-

MC000061	CN21995 Data Sheet + RoHS	3.5mm Pluggable Terminal Block, Plug, 8 Way, 26AWG to 16AWG, 10A MULTICOMP PRO The MC000061 is a 8-way 3.5mm pluggable PCB Terminal Block with tin plated phosphor bronze terminal, green polyamide 66 insulating body and straight block orientation. It accepts 16AWG wire gauge. • <gt/>2000MΩ Insulation resistance • -40 to +105°C Operati... You previously purchased this product. View in Order History	Each	1+ €1.4625 (€1.80) 10+ €1.3338 (€1.64) 50+ €1.2285 (€1.51)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	3.5mm	-	8Ways	-	26AWG	26AWG to 16AWG	16AWG	-	Screw	10A	300V	-

MP007141	CN22901 + RoHS	5 Pole Terminal Block / Splicing Connector with Lever Lock, 4mm, 450V AC, 32A MULTICOMP PRO This Multicomp Pro splicing connector with lever lock allows for solid, stranded and fine stranded cables to be connected together without the need for any tools. • Solid & Stranded Conductors: 4mm² • Voltage: 450V AC • Current: 32A You previously purchased this product. View in Order History	Each	1+ €0.3744 (€0.46) 50+ €0.351 (€0.43) 100+ €0.3276 (€0.40)	Restricted Item Minimum order of 1 items Multiples of 1 only Please enter a valid quantity Add Min: 1 Mult: 1	-	-	5Ways	-	-	-	-	4mm²	Push In Lock	32A	450V	-
