15" 600W Bass Driver 8 Ohm -

15-600LF

15-600LF - 15" 600W Bass Driver 8 Ohm
15-600LF - 15" 600W Bass Driver 8 Ohm

Image is for illustrative purposes only. Please refer to product description.

Manufacturer:
FANE FANE
Manufacturer Part No:
15-600LF
Order Code:
LS05901
Also Known As:
GTIN UPC EAN: 5060765030617
Technical Datasheet:
15-600LF   Datasheet
See all Technical Docs

Product Range Selector (Fane Bass Drivers 8Ω)

See all from this product range

Product Overview

The Sovereign 15-600LF is a very high output bass driver in 2 way ported enclosures. The cone membrane, manufactured from curvilinear paper, is much stronger and more durable than conventional paper alternatives. This allows the driver to combine high sensitivity with the structural integrity required to produce undistorted low frequencies at high output levels. The mechanical and electrical properties of the unit have been carefully optimised to allow extended low frequency output up to its rated power handling of 600W (AES). The driver is ideally suited for medium to large vented enclosures.
  • For use in pro-sound applications
  • Great for ported bass enclosure designs
  • Optimised cone pulp offering increased strength, durability and performance
  • 3" Copper voice coil
  • Ideally suited for medium to large vented enclosures
  • Magnet material: Ferrite
  • Frequency response: 38Hz to 3.5kHz
  • Baffle hole diameter: 13.85"
  • Chassis: Pressed Steel
  • Connectors : Solder tag
  • Output power: 2400W peak
  • EBP: 89.37Hz (suitable for closed speakers)
  • Dimensions (DxDia): 169x381mmØ
  • Weight: 9.4kg

Applications

Audio, Public, Hobby & Education, Domestic, Music, Installations, Education

Product Information


:
Subwoofer

:
381mm

:
8ohm

:
1200W

:
37Hz

:
98.5dBA

:
Round

:
38Hz

:
3.5kHz

:
Fane Bass Drivers 8Ω

:
Through Hole

:
2400W

:
169mm

Find similar products Choose and modify the attributes above to find similar products.

Technical Documents (1)

Also Known As

GTIN UPC EAN: 5060765030617
