10W Ceiling Speaker 3.3" 8 Ohm, IP54 -

DL 8OHM

DL 8OHM - 10W Ceiling Speaker 3.3" 8 Ohm, IP54

Image is for illustrative purposes only. Please refer to product description.

Manufacturer:
WHALE WHALE
Manufacturer Part No:
DL 8OHM
Order Code:
LS05234
Also Known As:
GTIN UPC EAN: 4007540501789
Technical Datasheet:
DL 8OHM   Datasheet
See all Technical Docs

Product Range Selector (WHALE Ceiling Speakers)

See all from this product range

Product Overview

8cm (3.3") ceiling mounted speaker with white metal cover (RAL 9010). Suitable for use in all types of hollow ceilings. Easy fitting in round cut-out using spring arms, electrical connection by spring-loaded terminal clips. A compact solution for home and professional use with good sound qualities. Suitable for hollow ceilings, for music and speech in shops, at home, hotels etc.
  • Moisturised cone
  • Metal basket, non-corrodible
  • Temperature & UV-resistant
  • Ball-resistant
  • Output power: 10W rms (max. 30W)
  • Nominal impedance: 8Ω (DC resistance: 6.7Ω)
  • Frequency response: 90Hz to 18kHz
  • Mean SPL: 84dB (1W@1m) max. 90dB
  • Resonant frequency: 190Hz
  • Magnetic induction: 0.7T (flux 130µWb)
  • Height of front pole-plate: 3mm
  • Voice coil diameter: 20mm
  • Dispersion: 112°
  • Height of winding: 4mm
  • Inductance of the voice coil: 0.48mH
  • Effective piston area: 31cm²
  • Mechanical Q factor: 2.72
  • Electrical Q factor: 1.43
  • Total Q factor: 0.94
  • Cutout diameter: 93mm
  • IP rating: IP54
  • Operating temperature: -40 to +110°C - EN 60068-2-1 (-40°C for 96h) up to the standards of the Germanischer Lloyd
  • Length of cable: 0.1m
  • Dimensions (HxWxD): 105x105x38mm
  • Weight: 330g

Applications

Audio, Business, Commercial, Education, Installations, Office, Public, Signalling

Product Information


:
90Hz

:
18kHz

:
105mm

:
105mm

:
38mm

:
WHALE Ceiling Speakers

Find similar products Choose and modify the attributes above to find similar products.

Technical Documents (1)

Also Known As

GTIN UPC EAN: 4007540501789
